Traxxas 71054-1 1/16 Scale RTR E-Revo 4WD Racing Monster Truck Green

The Award-Winning Innovation of E-Revo, in 1/16 Scale

Traxxas sets the standard for power, performance and innovation. All the quality and waterproof capability you expect from Traxxas is available in 1/16 scale with the 1/16 E-Revo. At 14 inches long, this E-Revo is about half the size of the 1/10-scale E-Revo. But don’t call it a “mini”—this is a whole new category of RC performance and fun that no mere mini-model can match. Beneath the factory-finished polycarbonate shell, you’ll find the winning suspension technology of the eight-time National Champion Traxxas Revo®, high-torque Titan 550 power, and the convention-busting innovation of the E-Revo.

Leave it to Traxxas to put the huge torque of the Titan 550 motor into the 1/16 E-Revo for unstoppable climbing, roosting, and monster performance! The Titan modified motor delivers exciting mod-motor power output with long-lasting performance. The Titan’s integrated cooling fan pulls cool air through vent tunnels molded into the motor plate to keep temperatures down. A cooler running motor equates to faster speeds, longer runtime, and extended motor life. The XL-2.5 Electronic Speed Control comes standard with three drive profiles, low voltage detection, thermal shutdown protection, gold-plated connectors, and incredibly low resistance. The patented Traxxas High-Current Connector opens the door for unrestricted current flow with today’s high-power batteries.

The 1/16 E-Revo packs all the innovation, durability and excitement of the race-winning Revo and E-Revo in a convenient take-anywhere size. The Revo’s rocker-actuated suspension carries over to 1/16 scale with all its functionality and performance intact, right down to the oil-filled, threaded-body GTR shocks. The suspension and electronics fully integrate into the semi-monocoque chassis. Intricately molded as a single piece, the chassis balances strength, weight, and performance to surpass the standards of the “mini” category.

The 1/16 E-Revo is fully assembled with TQ 2.4 GHz radio system, Titan 550 motor, XL-2.5 electronic speed control, painted and decaled body, pre-glued tires, and detailed instructions. An iD-Equipped Traxxas Power Cell NiMH battery and 2-amp peak detecting DC fast charger are also included, making the 1/16 E-Revo truly Ready-To-Race. Traxxas backs the 1/16 E-Revo and all of our products with top-notch support that is second to none. A staff of skilled representatives is on-hand to answer your questions via phone, website, or e-mail. Unmatched parts support allows the E-Revo to be serviced with parts and support from thousands of hobby dealers worldwide. Your investment is also protected by the Traxxas Lifetime Electronics Warranty. Traxxas goes the extra mile to ensure that your RC experience is easy and fun (and fast!).

FEATURES:

• 2-amp Peak Detecting DC Fast Charger
• Traxxas Power Cell NiMH battery with iD®
• TQ 2.4GHz radio system
• Revo suspension technology and integrated chassis design perfectly optimized for 1/16 scale
• Patented Traxxas High-Current Connector allows high-capacity battery packs to deliver maximum voltage
• XL-2.5 Waterproof Electronic Speed Control
• Innovative waterproof design
• LiPo and NiMH compatible with two-stage low-voltage detection
• Fully-proportional forward, reverse, and braking control
• Programmable with three drive profiles:
• Sport Mode – Fwd / Brake / Rev
• Race Mode – Fwd / Brake
• Patented Training Mode – 50% Fwd / Brake / 50% Rev
• EZ-Set® push-button setup
• Multi-color LED
• Thermal shutdown protection
• Efficient, low-loss MOSFET design
• High-capacity heat sink
• Smooth, high-frequency operation
• Easy installation in Traxxas models
• Titan® 12T Modified Motor
• Digital High-Torque Waterproof Micro Steering Servo (#2080)
• Waterproof, o-ring sealed receiver box
• Sealed, silicone-filled differentials—an industry first in 1/16 scale
• Torque-Control™ slipper clutch system
• Heavy-duty CV-style driveshafts
• Rubber-sealed ball bearings
• External gear cover with easy slipper access
• Extended-wheelbase rear suspension arms (+10 mm)
• Rocker-actuated shocks provide true progressive damping and spring rates
• Threaded-body, oil-filled shocks permit fast, precise preload adjustments and deliver smooth, consistent damping
• Fiber-composite monocoque chassis
• Speed control and receiver are securely fastened to chassis
• Integrated battery compartments with intake and exit cooling vents
• Quick-release battery doors for fast pack changes
• Pre-glued Talon™ Tires with foam inserts
• Black-chrome Gemini wheels

SPECIFICATIONS:

• Length: 12.9 inches (328 mm)
• Front Track: 9.4 inches (239 mm)
• Rear Track: 9.4 inches (239 mm)
• Weight: 44 ounces (1.24 kg)
• Height (overall): 4.6 inches (117 mm)
• Wheelbase: 7.9 inches (202 mm)
• Wheel Diameter 2.0″ (50.8 mm)
• Shock Length (front/rear): 48 mm / 48 mm
• Front/Rear Tires (glued): Talon™ 2.0″
• Front/Rear Wheels: 2.0″ Gemini™ (black-chrome)
• Electronic Speed Control: Waterproof XL-2.5 ESC
• Motor (electric): Titan® 12T 550
• Transmission: Heavy-Duty Single Speed
• Gear Ratio (internal): 5.04:1, (reversed input: 9.72:1)
• Overall Drive Ratio: 15.75:1 (stock, out-of-box)
• Differential Type: Hardened Steel Bevel, Sealed
• Gear Pitch: 48-Pitch
• Chassis Structure/Material: Molded Composite Nylon Monocoque
• Brake Type: Electronic
• Drive System: Shaft-Driven 4WD
• Steering: Bellcrank
• Transmitter: ­ TQ 2.4GHz Radio
• Receiver: #6519 3-Channel Micro
• Top Speed: 20+mph
• Skill Level: 1
• Battery Tray Dimensions: 89 mm x 35.5 mm x 20 mm
• Included Batteries: 6-cell Power Cell iD NiMH battery with 2-amp Peak Detecting DC Charger
• Required Batteries: 4 “AA” (transmitter)
