Tekin TT2302 1/8 RX8 Gen3 Brushless Sensored Crawler ESC

Tekin’s RX8 GEN3 brings bigger power handling capabilities and increased reliability to 1/8 Scale Racing. The RX8 platform has proven itself to handle the rigors of racing, while providing professional features including a programmable High Voltage BEC, Data Logging Capabilities, Timing Profiles, Voltage Cutoffs for LiPos, HotWire 3.0 Bluetooth Connectivity and more. Utilizing Tekin’s D2 Dual Drive Mode Technology, the RX8 runs both Sensored and Sensorless motor drives seamlessly, giving you the best of both worlds. The small footprint makes install on any chassis easy with the option of mounting with included hardware for extra security. Combo the RX8 GEN3 with a Tekin T8 Brushless Motor for 1/8 Scale Buggies and Truggies or a Pro4HD for 4WD Short Course domination!

FEATURES:

• Bluetooth Wireless Mobile and USB PC Tuning with the HotWire 3.0
• New HD Gold-plated Solder Posts for Easy Soldering
• ​ Multi-Fin High Efficiency Heat Sink and Optional High RPM Cooling Fan
• 3rd Channel Input for On-The-Fly Drag Brake Adjustments <<setup>>
• ​QuickTune™ One Touch Programming
• Adjustable Torque Control *
• Adjustable Throttle and Brake Frequencies *
• ​HD High Voltage Programmable BEC *
• HotWire™ Programming Port *
• Data Logging Capability *
• Sensor Checker
• On-Board Temperature Indicator
• ​ESC Self Diagnostics with Error Codes
• Fully Proportional Forward/Brake/Reverse
• ​Brushless and Brushed Motor Drive
• ​Sensored or Sensorless Operation
• ​LiPo Safe with Custom Voltage Cutoffs
• ​Sensor Plug for Precise Commutation
• ​HDAC: High Density Copper PCB’s
• Ultra-smooth and Precise Throttle and Braking Control

* requires HotWire™ sold separately.

SPECIFICATIONS:

• Controls: Forward/Brake/Reverse
• Input Voltage: 2S-6S LiPo / 4-16S NiMH-NiCD
• BEC: 6.0v / 7.4v @ 8amps
• Motor Limit Brushless Mode:
• 2S – No Limit
• 3S – 4000kV
• 4S – 3500kV
• 5S – 2200kV
• 6S – 2200kV
• Motor Limit Brushed Mode: No Limit
• Max Current: 300amps per phase*
• Burst Current: 1000amps per phase*
• Timing Profiles: 7 choices (on board)
• Brushed Modes: FWD Only / FWD-REV / FWD-REV Delay
• Brushless Modes: FWD Only / FWD-REV / FWD-REV Delay
• Dimensions: 1.5 x 2.2 x 1.4″ / 38 x 55.8 x 35.5mm
• Weight: 2.7oz / 76.5g

*Per Manufacturer Specs
